Do you know the function of G11 epoxy sheet on reactor?

Reactor in the whole electric power industry will always play a good man. It is a kind of reactive power compensation means, but also has an indispensable role. Do you know anything about this nice guy? Do you know what insulating material is used on it? What is the role of G11 fiberglass epoxy sheet material? I think a lot of people outside the industry would shake their heads and say "I don't know." It doesn't matter. Today I will give you a detailed analysis.

First of all, let's understand the material of G11 fiberglass sheet. Right?

G11 epoxy fiberglass sheet is one of the best materials in epoxy sheet at present. Good heat resistance (160-180 ℃), flame retardant (UL 94V-0), low water absorption (water absorption rate is almost 0; It is only 0.09% after immersion for 24 hours), high thermal stress (288 degrees) and other characteristics.

What is the insulation material on the reactor? You guessed it already. That's right, it's G11 fiberglass epoxy sheet. Now I'm going to talk to you about what its functions are on a reactor.

Anti-aging

Insulating materials in the reactor should bear the load generated by the reactor operation and the action of the surrounding environment. The sum, strength and action time of these loads determine the life of insulating materials. The G11 fiberglass sheet material is a new type of insulating material, which is less affected by the environment. This not only greatly increases its own life, but also delays the aging of the reactor.

Anti-static

Because of the alternating magnetic field generated by the reactor operation, the static current is generated. Not only will it absorb dust, but it is also a damage to insulating materials. The g11 material properties can avoid this situation.

High temperature resistant

Insulating materials will gradually lose their original mechanical and insulating properties under the action of high temperature, electric field and magnetic field for a long time. The high temperature resistance of G11 sheet is as high as 160-180 degrees. Only when the temperature exceeds this, G11 material will have deformation and other adverse conditions. In general, there is hardly any temperature above this. It can be used safely.

insulation

Insulation is very necessary in order to ensure the safe operation of the reactor and prevent the breakage, short circuit and fault caused by conduction.

The above is the function of G11 fiberglass sheet material used in the reactor collected by me. If there is something wrong, welcome to correct it, so as to ensure the reliability and accuracy of the uploaded information.
